Projection Mapping · Dubai & GCC
Lazulite plans, creates and runs projection mapping in Dubai, the UAE and across the GCC, on building facades, stage sets, cars, scale models and rooms. Our content designers build 3D content to the exact shape of your surface. Our engineers align the projectors and run every show night. Projection Mapping, Laser Projection and the Immersive Room are part of our catalogue of 40+ products. When a space is too bright to project, we suggest LED instead.
Why Event Teams Choose Projection Mapping
150+
Projection Shows Delivered
25+
Building Facades Mapped
100+
Stages, Cars and Models Mapped
500+
Minutes of 3D Content Created
Trusted by brands, venues and government teams in the GCC
Projection mapping is video projected onto a 3D surface, such as a building, stage set or product, and shaped to fit its exact form. It is also called 3D projection mapping, video mapping or, on buildings, architectural projection mapping. Software warps each frame to follow edges and curves instead of filling a flat rectangle. Lazulite surveys the surface, builds the content to its measurements and runs the show with its own engineers.
Building facades, stage sets, cars, scale models, tables, floors and the walls of a room can all be projection mapped. Unlike a flat LED screen built from panels, projection can follow curves, corners and carved detail. Light, matt surfaces give the clearest picture, while glass and dark finishes need more brightness. A tower facade needs many projectors working from a distance, while a car or model needs fewer, placed closer.
Projection mapping needs darkness or low light, a clear line from projector to surface, enough throw distance, steady power and a secure projector position. Outdoor facade shows also need weather cover and the right approvals. Lazulite measures all of this in a site survey, and the content is built to those measurements.
Lazulite engineers work with your agency once it has a story. They check the story against the surface and the audience's sightline, and flag any scene the projectors cannot show.
Lazulite's content designers and engineers work as one team. The people who model your facade or set also render the content and load it onto the media server. Content made in the studio is built to fit the surface on site.
Lazulite engineers align each projector on site, blend the overlaps between images and run each show night themselves. Lazulite Technology Services LLC works from Dubai Production City and runs shows in Abu Dhabi, Riyadh, Doha and across all 6 GCC countries.
Trusted by
1,500+
projects delivered since 2016
96%
client retention
Indoor projection mapping gives control of light, power and access, while outdoor building shows reach more people but depend on darkness, weather and approvals. Indoors, the venue sets the rules and a show can run at any hour. Outdoors, facade shows start after sunset and need power at each projector tower.
Choose indoor projection mapping for stage sets, cars, scale models, process walls and immersive rooms. The room can be darkened, the audience stands close and the show can loop all day. The Immersive Room suits a stand or a lobby, because it brings its own walls and projectors.
Outdoor building projection fits when the facade itself is the message, such as a tower, a hotel front or a heritage wall. It suits a public crowd that gathers after sunset. UAE audiences know the format at scale. Al Wasl Plaza at Expo City Dubai holds a Guinness World Records title for its 24,038 square metre interactive immersive dome.
Developers can map a tower facade at handover, or a scale model to show a community before it is built. Lazulite's Interactive Projection Mapping on Models lets buyers explore the plan on the model itself.
Hotels and venues mark openings, anniversaries and weddings by mapping their own facade, ballroom wall or lobby. With 50+ venues behind it, Lazulite checks access, power and rigging rules before the content is designed.
Government entities use facade projection to mark national days, such as Eid Al Etihad and Saudi National Day, and public festivals. Sharjah24 reported that the 15th Sharjah Light Festival lit 13 locations across the emirate in February 2026.
Lazulite can work as the white-label engineering team behind your agency, covering the survey, the content and the show. Bizzabo, an event software company, reported in 2025 that 74% of attendees value immersive experiences that allow them to disconnect. Only 38% of organisers prioritise them.
Lazulite engineers measure the facade or surface, light levels, throw distance, power and projector positions on site, by day and after dark.
Lazulite builds a 3D model of the surface from the survey, then agrees the storyboard, run time and budget range with you.
Lazulite content designers animate and render the content onto the model, and check that each edge, window and panel lines up.
Lazulite engineers rig the projectors, then align and blend each image in night tests before the first audience arrives.
Lazulite engineers run each show from the control position and check the alignment before each show begins.
The in-house crew behind every project
Engineers
Survey, align and run each projection system
Content designers
Model the surface and render the 3D content
Production crew
Rig projectors, towers and cabling on schedule
On-site support
Watch each show and fix faults live
A projection mapping budget depends on surface size, ambient light, projector count, content length and detail, show nights and approvals. A car or model indoors with a short loop sits at the lower end. A building facade over several nights sits higher, because it needs more projectors, towers and crew. Share the surface, its location and your dates, and Lazulite will price the run.
Projector costs rise with surface size and ambient light, because a larger or brighter scene needs more projectors and brighter ones. Indoor stage sets often run on projectors of 10,000 to 20,000 lumens. Building facades usually need stacked laser projectors of 20,000 lumens or more. Each extra projector adds rigging, power and alignment time.
3D content is priced by length and detail, and the show length sets how much must be rendered. A two-minute loop costs less than a ten-minute facade story with several scenes. Running costs follow the number of show nights and the crew each one needs. Reusing the content at later events spreads the cost.
Budget bands
Compact
One mapped object or room
Standard
A mapped stage set or wall
Flagship
A building facade show
Proven projection kit, fast
Rent vs custom
Every facade projection needs consent from the building owner, and approval from the relevant authority where the show needs it, as in public spaces. Lazulite prepares the drawings and documents the approval asks for. Indoor shows follow the venue's own rules. Raise projector positions on neighbouring roofs or land early, because other owners control them.
Projectors need a clear line to the surface, the right throw distance, power and a secure, level base. Lazulite fixes each position in the site survey. Outdoors, projectors sit in covered housings or towers that protect them from heat, dust and humidity. Night access is booked in advance for alignment and tests.
A projection show needs an audience area with a clear view of the surface and safe routes in and out. Lazulite marks viewing zones, cable routes and exits on the site plan, so crowds stay clear of equipment. Agree who insures the projectors and the audience area before the first show night.
Can’t find your answer? Speak with our Dubai team.
Projection content usually takes two to four weeks for a short loop on a car or model. A building facade show with several scenes typically takes six to ten weeks. Lazulite's content designers create it in-house and build it to the site survey. Lazulite confirms your timeline once the surface and projector positions are fixed.
Let’s build it together
Tell us what you want to project onto, from a building facade to a car, and when the show runs. Our Dubai team will come back with a content idea, a projector plan and a budget range. Lazulite's engineers and content designers then survey, build and run the show in any of the 6 GCC countries. Send your brief, or call or message us on WhatsApp.
